PLANET - IGS-5225-8P2T2S - Managed Ethernet Switch - 8-Port - Industrial - PoE+

MODEL: PLANET IGS-5225-8P2T2S L2+ Industrial 8-Port 10/100/1000T 802.3at PoE + 2-Port 10/100/1000T+ 2-Port 100/1000X SFP Managed Ethernet Switch INDUSTRIAL AREA DEPARTMENT/WORKGROUP POE SWITCH Providing up to 8 PoE+, in-line power interfaces, the IGS-5225-8P2T2S can easily build a power centrally controlled for IP phone system, IP camera system, or wireless AP group for Industrial network. For instance, 8 PoE IP cameras or wireless access points can be easily installed around the corner in the industrial environment for surveillance demands or for a wireless roaming network. Without the power-socket limitation, the IGS-5225-8P2T2S makes the installation of IP cameras or wireless AP easier and more efficient. FEATURES PHYSICAL PORT * 8 10/100/1000BASE-T Gigabit Ethernet RJ45 ports with IEEE 802.3at PoE+ Injector * 2 10/100/1000BASE-T Gigabit Ethernet RJ45 ports * 2 100/1000BASE-X mini-GBIC/SFP slots for SFP type auto detection * One RJ45 console interface for basic management and setup POWER OVER ETHERNET * Complies with IEEE 802.3at Power over Ethernet Plus/end-span PSE * Up to 8 IEEE 802.3af/802.3at devices powered * Supports PoE power up to 36 watts for each PoE port * Auto detects powered device (PD) * Circuit protection prevents power interference between ports * Remote power feeding up to 100m * PoE management features * Total PoE power budget control * Per port PoE function enable/disable * PoE admin-mode control * PoE port power feeding priority * Per PoE port power limit * PD classification detection * Intelligent PoE features * Temperature threshold control * PoE usage threshold control * PD alive check * PoE schedule INDUSTRIAL PROTOCOL * Modbus TCP for real-time monitoring in a SCADA system * IEEE 1588v2 PTP (Precision Time Protocol) INDUSTRIAL CASE AND INSTALLATION * IP30 aluminum case * DIN rail and wall-mount design * 48~56V DC, redundant power with polarity reverse protect function * Supports 5000V DC Ethernet ESD protection * -40 to 75 degrees C operating temperature DIGITAL INPUT AND DIGITAL OUTPUT * 2 Digital Input (DI) * 2 Digital Output (DO) * Integrate sensors into auto alarm system * Transfer alarm to IP network via email and SNMP trap LAYER 2 FEATURES * Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex) * High performance of Store-and-Forward architecture, and runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth * Storm Control support * Broadcast/Multicast/Unicast * Supports VLAN * IEEE 802.1Q tagged VLAN * Up to 255 VLANs groups, out of 4094 VLAN IDs * Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad) * Private VLAN Edge (PVE) * Protocol-based VLAN * MAC-based VLAN * Voice VLAN * GVRP (GARP VLAN Registration Protocol) * Supports Spanning Tree Protocol * IEEE 802.1D Spanning Tree Protocol (STP) * IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) * IEEE 802.1s Multiple Spanning Tree Protocol (MSTP), spanning tree by VLAN * BPDU Guard * Supports Link Aggregation * 802.3ad Link Aggregation Control Protocol (LACP) * Cisco ether-channel (static trunk) * Maximum 6 trunk groups with 4 ports per trunk group * Up to 8Gbps bandwidth (duplex mode) * Provides port mirror (1-to-1) * Port mirroring to monitor the incoming or outgoing traffic on a particular port * Loop protection to avoid broadcast loops * Supports ERPS (Ethernet Ring Protection Switching) * Compatible with Cisco Uni-directional link detection(UDLD) that monitors a link between two switches and blocks the ports on both ends of the link if the link fails at any point between the two devices * Link Layer Discovery Protocol (LLDP) LAYER 3 IP ROUTING FEATURES * Supports maximum 32 static routes and route summarization QUALITY OF SERVICE * Ingress Shaper and Egress Rate Limit per port bandwidth control * 8 priority queues on all switch ports * Traffic classification * IEEE 802.1p CoS * IP TOS/DSCP/IP precedence * IP TCP/UDP port number * Typical network application * Strict priority and Weighted Round Robin (WRR) CoS policies * Supports QoS and In/Out bandwidth control on each port * Traffic-policing policies on the switch port * DSCP remarking MULTICAST * Supports IPv4 IGMP snooping v1, v2 and v3 * Supports IPv6 MLD snooping v1 and v2 * Querier mode support * IGMP snooping port filtering * MLD snooping port filtering * MVR (Multicast VLAN Registration) SECURITY * IEEE 802.1x Port-based/MAC-based network access authentication * Built-in RADIUS client to cooperate with the RADIUS servers * TACACS+ login users access authentication * RADIUS/TACACS+ users access authentication * IP-based Access Control List (ACL) * MAC-based Access Control List * Source MAC/IP address binding * DHCP snooping to filter distrusted DHCP messages * Dynamic ARP Inspection discards ARP packets with invalid MAC address to IP address binding * IP Source Guard prevents IP spoofing attacks * IP address access management to prevent unauthorized intruder MANAGEMENT * Switch Management Interfaces * Console/Telnet Command Line Interface * Web switch management * SNMP v1 and v2c switch management * SSH/TLS and SNMP v3 secure access * Four RMON groups (history, statistics, alarms, and events) * IPv6 IP address/NTP/DNS management * Built-in Trivial File Transfer Protocol (TFTP) client * BOOTP and DHCP for IP address assignment * Firmware upload/download via HTTP/TFTP * DHCP Relay and DHCP Option 82 * DHCP Server * User Privilege levels control * Network Time Protocol (NTP) * Link Layer Discovery Protocol (LLDP) * SFP-DDM (Digital Diagnostic Monitor) * Network Diagnositc * ICMPv6/ICMPv4 Remote Ping * Cable diagnostic technology provides the mechanism to detect and report potential cabling issues * Reset button for system reboot or reset to factory default * PLANET Smart Discovery Utility for deployment management SPECIFICATIONS HARDWARE * Copper Ports: * 8 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports * 2 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports(Port-9 to Port-10) * SFP/mini-GBIC Slots: * 2 1000BASE-SX/LX/BX SFP interfaces (Port-11 to Port-12) * Compatible with 100BASE-FX SFP * PoE Injector Port: 8 ports with 802.3at/af PoE injector function with Port-1 to Port-8 * Console: 1 x RJ45-to-RS232 serial port (115200, 8, N, 1) * Switch Architecture: Store-and-Forward * Switch Fabric: 24Gbps/non-blocking * Throughput (packet per second): 17.85Mpps@ 64 bytes packet * Address Table: 8K entries, automatic source address learning and aging * Shared Data Buffer: 4Mbits * Flow Control: * IEEE 802.3x pause frame for full-duplex * Back pressure for half-duplex * Jumbo Frame: 9Kbytes * Reset Button: * < 5 sec: System reboot * > 5 sec: Factory default * ESD Protection: 5KV DC * Enclosure: IP30 aluminum case * Installation: DIN rail kit and wall-mount kit * Connector: * Removable 6-pin terminal block for power input * Pin 1/2 for Power 1, Pin 3/4 for fault alarm, Pin 5/6 for Power 2 * Removable 6-pin terminal block for DI/DO interface * Pin 1/2 for DI 1 & 2, Pin 3/4 for DO 1 & 2, Pin 5/6 for GND * Alarm: One relay output for power failure. Alarm relay current carry ability: 1A @ 24V DC * DI/DO: * 2 Digital Input (DI): * Level 0: -24V~2.1V (±0.1V) * Level 1: 2.1V~24V (±0.1V) * Input load to 24V DC, 10mA max. * 2 Digital Output (DO): * Open collector to 24V DC, 100mA max. * LED Indicator: * System: * ?Power 1 (Green) * ?Power 2 (Green) * ?Fault Alarm ( Red ) * ?Ring (Green) * ?Ring Owner (Green) * ?DIDO ( Red ) * Per 10/100/1000T RJ45 PoE+ Ports: * ?PoE-in-Use (Orange) * ?LNK/ACT (Green) * Per SFP Interface: * ?100 LNK/ACT (Orange) * ?1000 LNK/ACT (Green) * Dimensions (W x D x H): 72 x 107 x 152 mm * Weight: 991g * Power Requirements: Dual 48~56V DC (>51V DC for PoE+ output recommended) * Power Consumption: * Max. 7.3 watts/25.04BTU (Power on without any connection) * Max. 252.3 watts/865.64BTU (Full loading with PoE function) POWER OVER ETHERNET * PoE Standard: IEEE 802.3at Power over Ethernet Plus/PSE * PoE Power Supply Type: End-span * PoE Power Output: * IEEE 802.3af Standard: Per port 48V~51V DC (depending on the power supply), max. 15.4 watts * IEEE 802.3at Standard: Per port 51V~56V DC (depending on the power supply), max. 36 watts * Power Pin Assignment: 1/2(+), 3/6(-) * PoE Power Budget: Dual power input: 240W maximum (depending on power input) * Max. Number of Class 2 PDs: 8 * Max. Number of Class 3 PDs: 8 * Max. Number of Class 4 PDs: 8 LAYER 2 FUNCTION * Basic Management Interfaces: Console; Telnet; Web browser; SNMP v1, v2c * Secure Management Interfaces: SSH, TLS, SNMP v3 * Port Configuration: * Port disable/enable * Auto-negotiation 10/100/1000Mbps full and half duplex mode selection * Flow control disable/enable * Power saving mode control * Port Status: Display each port’s speed duplex mode, link status, flow control status, auto negotiation status, trunk status * Port Mirroring: * TX/RX/both * 1 to 1 monitor * VLAN: * 802.1Q tagged based VLAN, up to 255 VLAN groups * Q-in-Q tunneling * Private VLAN Edge (PVE) * MAC-based VLAN * Protocol-based VLAN * Voice VLAN * MVR (Multicast VLAN Registration) * Up to 255 VLAN groups, out of 4094 VLAN IDs * Link Aggregation: * IEEE 802.3ad LACP/static trunk * Supports 6 trunk groups with 4 ports per trunk group * QoS: * Traffic classification based, strict priority and WRR * 8-level priority for switching * Port number * 802.1p priority * 802.1Q VLAN tag * DSCP/TOS field in IP packet * IGMP Snooping: * IPv4 IGMP (v1/v2/v3) snooping, up to 255 multicast groups * IPv4 IGMP querier mode support * MLD Snooping: * IPv6 MLD (v1/v2) snooping, up to 255 multicast groups * IPv6 MLD querier mode support * Access Control List: * IP-based ACL/MAC-based ACL * Up to 123 entries * Bandwidth Control: * Per port bandwidth control * Ingress: 500Kb~1000Mbps * Egress: 500Kb~1000Mbps * SNMP MIBs: * RFC 1213 MIB-II * IF-MIB * RFC 1493 Bridge MIB * RFC 1643 Ethernet MIB * RFC 2863 Interface MIB * RFC 2665 Ether-Like MIB * RFC 2819 RMON MIB (Groups 1, 2, 3 and 9) * RFC 2737 Entity MIB * RFC 2618 RADIUS Client MIB * RFC 2933 IGMP-STD-MIB * RFC 3411 SNMP-Frameworks-MIB * IEEE 802.1X PAE * LLDP * MAU-MIB LAYER 3 FUNCTION * IP Interfaces: Max. 8 VLAN interfaces * Routing Table: Max. 32 routing entries * Routing Protocols: * IPv4 software static routing * IPv6 software static routing STANDARDS CONFORMANCE * Regulatory Compliance: FCC Part 15 Class A, CE * Stability Testing: * IEC60068-2-32 (free fall) * IEC60068-2-27 (shock) * IEC60068-2-6 (vibration) * Standards Compliance: * IEEE 802.3 10BASE-T * IEEE 802.3u 100BASE-TX/100BASE-FX * IEEE 802.3z Gigabit SX/LX * IEEE 802.3ab Gigabit 1000T * IEEE 802.3x flow control and back pressure * IEEE 802.3ad port trunk with LACP * IEEE 802.1D Spanning Tree Protocol * IEEE 802.1w Rapid Spanning Tree Protocol * IEEE 802.1s Multiple Spanning Tree Protocol * IEEE 802.1p Class of Service * IEEE 802.1Q VLAN tagging * IEEE 802.1ad Q-in-Q VLAN stacking * IEEE 802.1X Port Authentication Network Control * IEEE 802.1ab LLDP * IEEE 802.3af Power over Ethernet * IEEE 802.3at Power over Ethernet Plus * IEEE 1588 PTPv2 * RFC 768 UDP * RFC 793 TFTP * RFC 791 IP * RFC 792 ICMP * RFC 2068 HTTP * RFC 1112 IGMP v1 * RFC 2236 IGMP v2 * ITU G.8032 ERPS Ring ENVIRONMENT * Operating Temperature: -40 ~ 75 degrees C * Storage Temperature: -40 ~ 85 degrees C * Humidity: 5 ~ 95% (non-condensing)
